Enhance your desktop computing experience with the robust ASUS P8Z77-V-BO-R motherboard, engineered to provide a reliable foundation for high-performance builds. Whether you are an IT professional constructing a workstation or a PC enthusiast assembling a gaming system, this feature-rich board delivers the stability and compatibility required for demanding tasks.
At sasconnects.com, we are committed to providing IT professionals and builders with dependable hardware at competitive pricing. This motherboard is available to order and ready for your next project, with dispatch in 2-4 business days and tracked UK and international delivery options available. Choose our high-quality components to ensure your system performs at its best.
| Brand | ASUS |
| SKU | P8Z77-V-BO-R |
| Brand | ASUS |
| Weight | 8.00 LBS |
| Form Factor | ATX |
| CPU Socket Type | LGA 1155 |
| Supported CPU(s) | Intel Celeron Processor, Intel Core i3 Processor, Intel Core i5 Processor, Intel Core i7 Processor, Intel Pentium Processor |
| Supported CPU Technologies | Intel Turbo Boost Technology |
| Chipset | Intel Z77 Express |
| Number of Memory Slot(s) | 4 |
| Number of Memory Channel(s) | 2 |
| Supported Memory Standard(s) | PC3-10600 (DDR3-1333), PC3-12800 (DDR3-1600), PC3-14900 (DDR3-1866), PC3-16000 (DDR3-2000), PC3-19200 (DDR3-2400), PC3-8500 (DDR3-1066) |
| Maximum Installed Memory | 32 GB |
| Expansion Slots | PCI-E 2.0 x1, PCI-E 2.0 x16 |
| Expansion Slots Details | 2 x PCIe 3.0/2.0 x16 (x16 or dual x8) *3, 1 x PCIe 2.0 x16 (x4 mode, black), 2 x PCIe 2.0 x1 *4, 2 x PCI |
| Storage Controller | SATA 3.0 Gbps, SATA 6.0 Gbps |
| Audio Controller | Realtek ALC892 |
| Network | Gigabit Ethernet |
| Connectors/Ports | Audio-In, Audio-Out, Chassis Fan Connector, CPU Fan Connector, D-Sub, DisplayPort, DVI-D, HDMI, PS/2 Keyboard, PS/2 Mouse, RJ-45, TPM Header, USB 2.0, USB 3.1 |
| Connectors/Ports Details | Back I/O Ports, 1 x PS/2 keyboard/mouse combo port(s), 1 x DVI-D, 1 x D-Sub, 1 x DisplayPort, 1 x HDMI, 1 x LAN (RJ45) port(s), 4 x USB 3.1 Gen 1, 2 x USB 2.0, 1 x Optical S/PDIF out, 6 x Audio jack(s), 1 x WLAN connector(s) for ASUS wireless module, |
